Mechanical Based Machine
| Technical Specifications | |
|---|---|
| Sealing Type | Centre seal or 3 or 4 Side Sealing |
| Filling Type | cup filler |
| Roll Width | Min 80mm Max. 500mm |
| Main Motor | ½ hp 1440 rpm |
| Heater Load | 1Kw |
| Electrical Supply | 1 Phase, 240 V / AC, 50 Hz |
| Packing Film | Any heat Sealable Laminate |
| Filling Range | 10-50grams, 50-250grams, 250-500grams ,500-1000grams |
| Temperature Controller | PID based |
| Machine Speed | depends upon the gram age that has to be packed |
| Contact Parts | Food Grade Stainless Steel SS 304 |
| Speed / machine Control | pulley and belt |
| Net Weight | 500 Kg. (Approx) |
| Optional Attachments | Hot foil Coding/inkjet coding, Nitrogen Flushing Device, take away elevator ( At an extra cost ) |
| Technical Specifications | |
|---|---|
| Sealing Type | Centre seal or 3 or 4 Side Sealing |
| Filling Type | Auger filler |
| Roll Width | Min 80mm Max. 500mm |
| Main Motor | ½ hp 1440 rpm |
| Heater Load | 1Kw |
| Electrical Supply | 1 Phase, 240 V / AC, 50 Hz |
| Packing Film | Any heat Sealable Laminate |
| Filling Range | 10-50grams, 50-250grams, 250-500grams ,500-1000grams |
| Temperature Controller | PID based |
| Machine Speed | depends upon the gram age that has to be packed |
| Contact Parts | Food Grade Stainless Steel SS 304 |
| Speed / machine Control | pulley and belt |
| Net Weight | 500 Kg. (Approx) |
| Optional Attachments | Hot foil Coding/inkjet coding, Nitrogen Flushing Device, take away elevator ( At an extra cost ) |
| Technical Specifications | |
|---|---|
| Type of seal | 3 side or Four side seal |
| Packaging Material | Shampoo, Lubrication oil, wine, syrup, juice and other free flowing liquid |
| Weight of the material | 6ml to 25ml, 30ml to 100ml |
| Filing system | Volumetric piston filing |
| Filing accuracy | +/- 1 % |
| Size of bags | W - 50 mm to 140mm L - 50mm to 130mm |
| Speed/Capacity | 20 to 50 bag/min |
| Power Consumption | Motor ½ HP/220V Single Phase Heater 300 x 2 = 600 W + 300 x 2 = 600 W main load 3.5 Kw |
| Film/roll material | 0.D of Roll 250mm max. ID of Roll pipe 75mm min. |
| Net weight | 380kg |
| Gross weight | 480kg |
| Technical Specifications | |
|---|---|
| Type of seal | 3 side or Four side seal |
| Packaging Material | Shampoo, Lubrication oil, wine, syrup, juice and other free flowing liquid |
| Weight of the material | 6ml to 25ml, 30ml to 100ml |
| Filing system | Volumetric piston filing |
| Filing accuracy | +/- 1 % |
| Size of bags | W - 50 mm to 140mm L - 50mm to 130mm |
| Speed/Capacity | 20 to 50 bag/min |
| Power Consumption | Motor ½ HP/220V Single Phase Heater 300 x 2 = 600 W + 300 x 2 = 600 W main load 3.5 Kw |
| Film/roll material | 0.D of Roll 250mm max. ID of Roll pipe 75mm min. |
| Net weight | 380kg |
| Gross weight | 480kg |
